Smart Controller
The smart controller enables riders to make real-time adjustments to the bike's power settings with ease. Increase or decrease power output to customize performance for different riding conditions.
Description
This rear-hub fat-tire electric bike is designed for hunting, off-road travel, and riding across dirt, mud, gravel, and other rough terrain. It uses a single rear-wheel hub motor and is not an all-wheel-drive model.
The 20Ah battery configuration provides a stated range of up to 65 miles using pedal assist or up to 32 miles using throttle only. The electric drive system produces 90Nm of torque and supports speeds of up to 30 mph.
Fat all-terrain tires, hydraulic brakes, an 8-speed drivetrain, integrated lighting, front and rear fenders, and a rear cargo rack provide a practical setup for recreational riding and equipment transport.
Performance Overview
- Range: Up to 65 miles using pedal assist or 32 miles using throttle only
- Speed: Up to 30 mph
- Battery: 48V 20Ah
- Weight: 68 lbs. with battery removed
- Motor: 750W–1000W rear hub motor powered by Bafang
- Drivetrain: 8-speed cassette drivetrain with 5 levels of pedal assist
Key Features
- Rear-Hub Drive: The motor is positioned in the rear wheel and delivers power directly to the rear wheel rather than through the chain or drivetrain.
- Motor Performance: The electric drive system provides 1000W nominal power, a 1200W peak rating, and 90Nm of torque.
- 20Ah Battery: The upgraded 48V 20Ah battery increases the available riding range compared with the standard 15Ah configuration.
- Extended Riding Range: The 20Ah battery provides up to 65 miles using pedal assist or up to 32 miles using throttle only.
- 8-Speed Drivetrain: The rear cassette provides 8 gears for adjusting pedaling effort across different terrain.
- Five Pedal-Assist Levels: Pedal Assist levels 1 through 5 provide progressively increasing motor assistance, while level 0 disables motor assistance.
- Adjustable Class System: Display settings allow selection of Class 1, Class 2, Class 3, or unlimited-power operation where permitted.
- Throttle Control: The throttle provides motor assistance based on the selected pedal-assist level.
- Walk-Assist Mode: Holding the minus button activates walk assist, allowing the bike to propel itself while the rider walks beside it.
- Smart Controller: The controller allows real-time adjustments to the bike’s power settings.
- Hydraulic Brakes: Front and rear Logan hydraulic brakes use dual-piston pads and integrated electric safety cutoffs.
- All-Terrain Tires: Kenda 24-inch x 4-inch tires feature anti-puncture technology for rough and off-road terrain.
- Double-Wall Rims: Aluminum alloy double-wall rims are designed to help prevent damage during off-road and rough-trail use.
- Waterproof LCD Display: The integrated digital display shows power, speed, battery level, and mileage.
- USB Charging: The bike includes a USB port for charging compatible USB-powered devices while the bike is turned on.
- Integrated Rear Rack: The built-in rear rack provides a platform for carrying gear, groceries, hunting equipment, and everyday essentials.
- Integrated Lighting: A headlight and taillight are preinstalled, and the taillight also functions as a brake light.
- Front and Rear Fenders: Built-in fenders help keep water, mud, and debris away from the rider.
- Electric-Bike Chain: The KMC Z8 chain is designed for electric-bike power.
- Extra-Wide Pedals: Wellgo aluminum alloy pedals provide a wide platform for the rider’s feet.
- Dual-Battery Capability: The frame allows a compatible 48V 14Ah secondary battery to be installed above the internal battery.
Waterproof LCD Display
The digital LCD display is tough and waterproof, showing important information including power, speed, battery level, and mileage. Its Adjustable Class Setting lets you switch between Class 1, 2, or 3 riding modes.
Integrated Rear Rack and Taillight
Designed for utility and safety, the integrated rear rack provides a sturdy platform for carrying gear, groceries, hunting equipment, and daily essentials. The built-in LED taillight improves rear visibility.
Front and Rear Fenders
“Let's get dirty”—or not! Built-in front and rear fenders help provide a cleaner ride through dirt and mud. Take on tough terrain with confidence using the bike's anti-puncture tires.
LG Branded 15 AH Battery
Put your mind at ease with a safety-certified 48V 15Ah battery equipped with dependable LG-branded cells.
Specifications
- Motor Type: Rear hub motor powered by Bafang
- Nominal Motor Power: 1000W
- Peak Motor Power: 1200W
- Torque: 90Nm
- Drive Type: Hub-drive
- Battery Voltage: 48V
- Battery Capacity: 20Ah
- Pedal-Assist Range: Up to 65 miles
- Throttle-Only Range: Up to 32 miles
- Maximum Speed: Up to 30 mph
- Drivetrain: 8-speed cassette
- Pedal Assist: Levels 0–5
- Front Brake: 180 mm Logan hydraulic brake with dual-piston pads and integrated electric safety cutoff
- Rear Brake: 180 mm Logan hydraulic brake with dual-piston pads and integrated electric safety cutoff
- Tires: Kenda 24-inch x 4-inch all-terrain tires with anti-puncture technology
- Rims: Double-wall aluminum alloy
- Chain: KMC Z8
- Frame: High-grade 6061 T6 aluminum
- Pedals: Extra-wide Wellgo aluminum alloy
- Display: Integrated waterproof digital LCD with Adjustable Class System
- Class Settings: Class 1, Class 2, Class 3, and unlimited power
- Lighting: Integrated headlight, taillight, and brake-light function
- Rear Rack: Integrated cargo rack
- Fenders: Integrated front and rear fenders
- Bike Weight: 68 lbs. with battery removed
- Maximum Load Capacity: 300 lbs.
Size Guide
- Minimum Rider Age: 18 years
- Rider Fit Requirement: The rider must be able to reach the ground while seated.
- Maximum Weight Limit: 300 lbs.
Compatibility
- Compatible Secondary Battery: 48V 14Ah dual battery
Included
- Electric bike
- Fully integrated waterproof digital LCD with Adjustable Class Setting
- 48V 20Ah battery
- Smart charger
- Bike manual
The bike arrives almost fully assembled. Final assembly is required before riding.
Warranty
- Lifetime Frame Warranty: The frame is warranted against factory defects for the lifetime of the original purchaser while they remain the owner. This coverage is nontransferable.
- Manufacturer Warranty: The bike, enclosed hardware, and accessories are warranted against defects in materials or workmanship for 1 year.
- Registration Requirement: The original owner must register the bike using its serial number within 30 days of receiving it.
