The Baystone Fountain is designed for small residential ponds and creates a distinctive center peak surrounded by a traditional outer spray pattern. Its water display adds visual movement while helping support a healthier aquatic environment.
This configuration uses a ½-hp, 115-volt motor with a 70-foot power cable. Its stainless-steel, oil-free, submersible motor requires no oil changes, routine maintenance, or separate control box.
The fountain is suitable for fresh or salt water and is engineered to remain installed during freezing weather. Power should be switched off during freezing conditions and restored after the ice thaws.
Key Features
Distinctive Water Display: Produces a center peak surrounded by a traditional outer spray pattern.
Residential Pond Application: Designed specifically for small residential ponds.
Oil-Free Operation: Uses an oil-free motor, eliminating the need for oil changes.
Submersible Motor: Built with a stainless-steel, submersible motor for pond installation.
Low-Maintenance Design: No routine maintenance or separate control box is required.
Freshwater and Saltwater Use: Designed for operation in both fresh and salt water.
Cold-Weather Durability: May remain installed during freezing weather after the power is turned off. Power can be restored after the ice thaws.
Optional Lighting: The product page provides a selectable light-set option for adding fountain illumination.
Made in the USA: Manufactured in Holland, Michigan.
Specifications
Motor Power: ½ hp
Voltage: 115 V
Current Draw: 10 amps
Supplied Cable Length: 70 feet
Supplied Cable Gauge: 12 gauge
Minimum Anchor Weight: 25 pounds each
Maximum Main-Breaker Distance: For proper operation of the 115-volt motor, the distance from the main breaker to the fountain must not exceed 100 feet. A 230-volt motor should be selected when the distance exceeds 100 feet.
Motor Construction: Stainless-steel, oil-free and submersible
Water Compatibility: Fresh water and salt water
Maintenance Requirement: No routine maintenance or oil changes required
Control Box Requirement: No control box required
Required Electrical Protection: Ground Fault Circuit Interrupter required
Swimmer Safety: Disconnect power whenever swimmers are present.
Testing and Compliance: ARL-tested and compliant with applicable UL standards and the National Electrical Code when installed as a complete package.
Compatibility
Compatible With: Small residential freshwater and saltwater ponds.
Electrical Application: 115-volt installations where the distance from the main breaker to the fountain does not exceed 100 feet.
Included
70-foot, 12-gauge supplied electric cable
Not Included
Light set Not Included
